UL1354 Coaxial Cable 同轴电缆

■ 说明：
●导体使用40AWG以上单条或绞线，裸软铜或镀锡软铜线
●实心，发泡或耐燃PE绝缘
●裸软铜或镀锡软铜线编织隔离
●低损失，低时延及干扰可减至最小
●额定温度：60℃或80℃；额定电压：30volts
●可通过UL VW-1 垂直耐燃测试
●参考标准：UL 758，UL 1581


■ 应用：
●用于电视机，收音机，接收机，录音机等内部或外部连线

■ PRODUCT DESCRIPTION：
●Tinned or bare,stranded or solid copper conductor,
   40AWG minimum.
●Solid or foamed or  FR-PE insulation.
●Tinned or bare copper wire spiral shield.
●Low losses and low propagation delays,Cosstalk kept to minimum.
●Rated temperature：60℃ or 80℃.Rated voltage：30 volts.
●Passes UL VW-1 vertical flame test.
●Reference standard：UL subject 758，UL 1581.

■ APPLICATIONS：
●Forinternal orexternal wiring of TV，radio，receiver，VTR，tape recorder & etc.
